Door Axis 32 in x 80 in 9-Lite Clear Glass Fiberglass Prehung Front Door with Brickmold
Reviewed pricing, lead time, freight, and final configuration are confirmed during quote review before order release.
The Door Axis 9-Lite Clear Glass Fiberglass Prehung Front Door pairs a smooth fiberglass slab with a nine-pane clear glass upper half on a weatherstripped, brickmolded frame. It serves homeowners who want daylight at the entry with a low-maintenance skin that shrugs off the dents, rust, and rot that wear on steel and wood doors.
The slab is molded with high-definition profiles and true square-edge engineered stiles over an energy-saving polyurethane foam core, so it keeps its shape through harsh weather without cracking, warping, or splitting. The upper half carries a nine-lite grid of dual pane tempered clear glass over a two-panel base, lighting the foyer while the paint-ready primed white face keeps the look crisp. Each unit arrives fully assembled on a primed wood frame with three nickel-finish hinges, factory brickmold, aluminum sill, and compression weatherstripping, double bored for a lockset and deadbolt, in 32 and 36 in widths hung left- or right-hand inswing.
Highlights
- Smooth fiberglass slab resists cracking, warping, splitting, and denting
- 9-lite clear glass upper half in dual pane tempered safety glass
- Energy-saving polyurethane foam core; ENERGY STAR qualified construction
- True square-edge engineered stiles for dimensional stability in harsh climates
- Prehung on a 4-9/16 in primed wood frame with factory brickmold and aluminum sill
- Double bored for lockset and deadbolt, hardware sold separately
- Primed white face ready for field paint in any color
Specification Table
| Configuration | Single door, prehung with brickmold |
| Nominal slab size | 32 or 36 in x 80 in |
| Slab thickness | 1.75 in |
| Rough opening | 34.25 x 82 in (32 in); 38.25 x 82 in (typical, 36 in) |
| Jamb | 4-9/16 in primed wood jamb |
| Material | Smooth fiberglass skin over polyurethane foam core |
| Glazing | 9-lite clear glass, dual pane tempered, half lite layout |
| Panel profile | 2-panel base below the glazed half |
| Handing | Left-Hand Inswing or Right-Hand Inswing |
| Hardware prep | Double bore for lockset and deadbolt; 3 nickel-finish hinges |
| Weatherstripping | Perimeter compression weatherstripping with aluminum sill |
| Finish | Primed white, paint ready |
| Weight | 115 lb (32 in x 80 in unit) |
| Warranty | Limited lifetime manufacturer-backed warranty, confirmed during quote review |
Included Components
- Fiberglass slab with factory-glazed 9-lite clear glass insert
- Primed wood frame with factory-applied brickmold
- Three nickel-finish hinges, factory installed
- Aluminum sill and perimeter compression weatherstripping
- Double bore lockset and deadbolt prep; lockset and deadbolt sold separately
Installation Notes
- Verify the rough opening is about 2.25 in wider and 2 in taller than the nominal slab size and check plumb, level, and square before setting the unit.
- Set the sill in sealant over a sill pan and shim at hinge and strike points so the glazed slab does not rack.
- Fasten the hinge-side jamb first, checking reveals around the slab before securing the strike side.
- Integrate the brickmold with housewrap and flashing tape and seal the exterior perimeter, keeping the sill weep path clear.
- Finish paint the primed surfaces, including top and bottom slab edges, promptly after installation.
Warranty and Support
- Limited lifetime manufacturer-backed warranty, confirmed during quote review.
- Glazing and prep drawings are available with the quote package.
Frequently Asked Questions
Is the glass insulated?
Yes. The nine lites are dual pane tempered clear glass in a half lite layout, glazed at the factory.
Fiberglass or steel for my entry?
Fiberglass resists dents, rust, and rot, making it the better skin for coastal climates, kid and cart traffic, and unshaded exposures; this platform pairs that skin with a polyurethane core for energy performance.
What sizes and handings are offered?
Nominal 32 in x 80 in and 36 in x 80 in, each hung left- or right-hand inswing on a 4-9/16 in jamb.
Is a lockset included?
No. The slab is double bored for a standard lockset and deadbolt, ordered separately so you can match your hardware finish.
