Door Axis 36 in x 80 in 9-Lite Steel Prehung Entry Door with Brickmold, Left-Hand Inswing
Reviewed pricing, lead time, freight, and final configuration are confirmed during quote review before order release.
The Door Axis 9-Lite Steel Prehung Entry Door puts a nine-pane tempered glass upper half on a galvanized steel slab with high-definition panel profiles, hung left-hand inswing on a brickmolded frame. It serves budget-focused builds and back or side entries that still need daylight, security, and an insulated core.
The slab is formed from galvanized steel that resists rust and corrosion, wrapped around a polystyrene core that insulates the opening and helps lower heating and cooling loads, with the complete unit rating a 0.34 U-factor. The upper half carries nine clear tempered lites over a two-panel base, and the primed slab, frame, and brickmold are all paint-ready so the entry finishes as one piece. Each unit ships assembled on a weatherstripped 4-9/16 in frame with three satin nickel hinges, double bored for a lockset and deadbolt, in nominal 32 and 36 in widths hung left-hand inswing.
Highlights
- 9-lite clear tempered glass upper half over high-definition 2-panel styling
- Galvanized steel skin resists rust and corrosion
- Polystyrene insulating core; 0.34 U-factor unit performance
- Prehung on a 4-9/16 in frame with primed, paint-ready brickmold
- Double bored for lockset and deadbolt, hardware sold separately
- Three satin nickel hinges, hung left-hand inswing
- Nominal 32 and 36 in widths at 80 in height
Specification Table
| Configuration | Single door, prehung with brickmold |
| Nominal slab size | 32 or 36 in x 80 in |
| Slab thickness | 1.75 in |
| Unit dimensions | 37.44 in x 81.75 in overall (36 in size) |
| Rough opening | 38.5 x 82.25 in (36 in); 34.5 x 82.25 in (typical, 32 in) |
| Jamb | 4-9/16 in jamb, primed |
| Material | Galvanized steel skin over polystyrene core |
| Glazing | 9-lite clear glass, tempered, half lite layout |
| Thermal performance | U-factor 0.34; solar heat gain coefficient 0.34 |
| Handing | Left-Hand Inswing |
| Hardware prep | Double bore for lockset and deadbolt; 3 satin nickel hinges |
| Weatherstripping | Perimeter weatherstripping |
| Finish | Primed, paint ready |
| Weight | 53.44 lb (listed shipping weight, 36 in unit) |
| Warranty | 10 year limited manufacturer-backed warranty, confirmed during quote review |
Included Components
- Galvanized steel slab with factory-glazed 9-lite tempered clear glass insert
- Prehung frame with primed brickmold
- Three satin nickel hinges, factory installed
- Perimeter weatherstripping and sill
- Double bore lockset and deadbolt prep; lockset and deadbolt sold separately
- Installation instructions
Installation Notes
- Verify the rough opening at 38.5 x 82.25 in for the 36 in unit and check plumb, level, and square before setting.
- Set the sill in sealant over a sill pan and shim at hinge and strike points so the glazed slab hangs square.
- Fasten the hinge-side jamb into framing first, then adjust the strike side for an even reveal.
- Integrate the brickmold with housewrap and flashing tape and seal the exterior perimeter, keeping the sill weep path clear.
- Prime cuts and finish paint all primed surfaces promptly after installation to maintain corrosion protection.
Warranty and Support
- 10 year limited manufacturer-backed warranty, confirmed during quote review.
- Unit performance data and prep drawings are available with the quote package.
Frequently Asked Questions
Is this door only left-hand inswing?
This platform is stocked left-hand inswing. If your opening needs a right-hand door, the quote review can route you to the matching 9-lite steel platform in the catalog.
What does the 0.34 U-factor mean?
It is the whole-unit heat transfer rate, glass included: the lower the number, the better the insulation. A glazed steel entry at 0.34 performs well for a half lite door.
Is the glass tempered?
Yes, all nine lites are tempered safety glass, factory glazed in a half lite layout.
What rough opening do I need?
Frame 38.5 x 82.25 in for the 36 in door; the 32 in door runs about 34.5 x 82.25 in, confirmed during quote review.
Documents
- Type Steel Entry Door
- SKU DA-DR-EXT-STL9L-PH36-36
Download the available product documents below. If a document is not linked yet, use the SKU during quote review.
