Door Axis 36 in x 80 in Full View Interchangeable Aluminum Storm Door, Quick-Change Glass and Screen
Reviewed pricing, lead time, freight, and final configuration are confirmed during quote review before order release.
The Door Axis Full View Interchangeable Aluminum Storm Door is the premium full glass storm door in the line: a 1-1/2 in aluminum frame carrying full-height glass and insect screen panels that swap in under a minute with the flip of a handle. It serves homeowners who want a clear view of the entry in winter, whole-door ventilation in summer, and a frame heavy enough to stay square for decades.
The frame is heavy duty aluminum, 1-1/2 in thick with reinforced corners that keep the door square over years of slamming, weather, and seasonal swaps. The full glass panel and the full insect screen panel interchange without tools: release the retainer, lift one panel out, set the other in, done in under a minute. Dual weatherstripping runs across the top and down both sides with an additional layer on the handle side, and a double bottom sweep closes the threshold gap. The integrated closer system pulls the door to a smooth, quiet close with reinforced latch engagement, and the handle set carries a built-in keyed deadbolt. Nine factory finishes cover whites, warm neutrals, deep earth tones, black, and a forest green, and the door is ordered handed, left or right outswing, to match the entry behind it. Additional sizes, Low-E and insulating glass packages, laminated security glass with multi-point locking, and handle style upgrades are quoted on request.
Highlights
- Glass and screen panels interchange in under a minute, no tools
- Heavy duty 1-1/2 in aluminum frame with reinforced corners
- Full view: glass or screen spans the entire door opening
- Dual weatherstripping plus an extra handle-side layer and double bottom sweep
- Integrated closer system with smooth close and reinforced latch engagement
- Handle set with built-in keyed deadbolt, included
- Nine factory finishes from white to black and forest green
- Ordered Left-Hand or Right-Hand Outswing to match the entry
Specification Table
| Configuration | Single full view storm door, interchangeable glass and screen panels |
| Nominal size | 36 in x 80 in flagship; platform spans 30 to 36 in widths |
| Fits opening | 35-3/4 to 36-3/8 in x 80 to 80-7/8 in at the 36 in size |
| Frame | 1-1/2 in heavy duty aluminum, reinforced corners |
| Thickness | 1-1/2 in |
| Glazing | Clear tempered glass panel standard; Low-E and insulating packages quoted on request |
| Screen | Full-height interchangeable insect screen panel, included |
| Handing | Left-Hand Outswing or Right-Hand Outswing, ordered to the entry |
| Closer | Integrated closer system, smooth close, reinforced latch engagement |
| Hardware | Handle set with built-in keyed deadbolt, included; styles and finishes confirmed during quote review |
| Weatherstripping | Dual at top and sides, additional handle-side layer, double bottom sweep |
| Finishes | White, Almond, Sandtone, Terratone, Bronze, Black, Charcoal Gray, Cinnamon Toast, Forest Green |
| Weight | About 68 lb |
| Additional sizes | 30 to 36 in widths and security glass packages are quoted on request |
| Warranty | Limited lifetime manufacturer-backed warranty, confirmed during quote review |
Included Components
- Full view aluminum storm door, ordered handing and finish
- Full-height tempered glass panel and full-height insect screen panel
- Handle set with built-in keyed deadbolt
- Integrated closer system, factory fitted
- Tamper-proof hinge rail, installation hardware, and instructions
- Double bottom sweep and factory weatherstripping
Installation Notes
- Measure the existing entry opening width and height at three points each; the 36 in size fits openings 35-3/4 to 36-3/8 in wide by 80 to 80-7/8 in tall.
- Check the mounting surface: the entry door frame face must be flat, sound, and deep enough for the hinge and latch rails along their full height.
- Order the handing to match the entry door so both doors swing the same direction; outswing handing is confirmed from an exterior view during quote review.
- Adjust the integrated closer after hanging so the door closes fully and quietly without slamming, then verify the keyed deadbolt throws cleanly.
- Swap the glass and screen panels once at installation to learn the quick-change action, and store the off-season panel flat in a dry space.
Warranty and Support
- Limited lifetime manufacturer-backed warranty, confirmed during quote review.
- Quote review covers opening measurements, handing, finish, glass package, and handle style before release.
Frequently Asked Questions
How does the quick-change system work?
The full glass and full screen panels sit in the same opening. Release the retainer, flip the handle, lift out one panel and set in the other; the swap takes under a minute and needs no tools.
How is this different from the retractable screen model?
The retractable model hides a screen in the top rail for instant partial ventilation. This interchangeable platform swaps full-height panels seasonally, giving whole-door ventilation in summer and an uninterrupted glass view in winter, on a heavier 1-1/2 in frame.
Which handing do I order?
Stand outside facing the entry. The storm door should hinge on the same side as the entry door behind it; order Left-Hand or Right-Hand Outswing to match. Handing is confirmed during quote review.
Are other sizes and glass packages available?
Yes. The platform spans 30 to 36 in widths, and Low-E, insulating dual pane, and laminated security glass with multi-point locking are quoted on request.
Documents
- Type Aluminum Storm Door
- SKU DA-DR-STM-FV-INT-3680-RH-WH
Download the available product documents below. If a document is not linked yet, use the SKU during quote review.
Project pricing, lead time, freight routing, and final configuration are confirmed during quote review before order release.
Support and request quote workflows stay available throughout specification and order planning.
