Door Axis 36 in x 80 in Unfinished Wood Hinged Screen Door, Charcoal Fiberglass Mesh

The Door Axis Unfinished Wood Hinged Screen Door is a traditional swinging screen door built with mortise and tenon joinery and charcoal fiberglass mesh, ready to paint or stain to match the porch. It serves homeowners who want the look and slam-proof feel of a real wood screen door, with configurations for households with pets.

The stiles and rails are wood joined with mortise and tenon craftsmanship, the same joinery used in cabinetry, so the frame resists the sagging and warping that stapled screen doors develop. Three configurations share the platform: Classic carries open screen the full height in pressure-treated stock, Pet Grille adds a heavy duty grille that shields the lower screen from active paws, and Pet Flap builds in a tinted vinyl pet entry rated for pets up to 90 lb with a lock-out slide for unsupervised hours. The charcoal fiberglass mesh sets in a spline so it removes cleanly for repainting or screen replacement, and the frame trims up to 3/8 in on the top and sides and 1 in on the bottom to fit existing openings. The door hangs on either side, and hinge and latch kits with spring-loaded self-closing hinges are quoted on request since hardware is not included.

Highlights

• Mortise and tenon joinery resists sagging and warping
• Natural unfinished wood, ready to paint or stain
• Charcoal fiberglass mesh, spline-set and removable for repair
• Pet Grille configuration shields the lower screen from active pets
• Pet Flap configuration passes pets up to 90 lb, with lock-out slide
• Frame trims up to 3/8 in top and sides, 1 in bottom, for a fitted install
• Universal Reversible: hangs left or right
• Spring hinge and latch kits quoted on request

Specification Table

Included Components

• Wood hinged screen door in the selected configuration
• Charcoal fiberglass mesh, factory installed with removable spline
• Pet grille or pet flap hardware when those configurations are selected
• Installation instructions (hinges, latch, and pulls sold separately)

Installation Notes

• Measure the entry opening width and height at three points each; the frame trims up to 3/8 in per side and top and 1 in at the bottom to fit.
• Check the mounting surface: the door hangs from the side casing or jamb face, which must be flat and solid where the hinges land.
• Choose the hinge side to match traffic flow; the door is universal reversible.
• Finish the door before hanging: paint or stain all six sides, including the trimmed edges, so the wood cannot draw moisture and warp.
• Use three spring-loaded self-closing hinges and set their tension so the door closes gently; add the hook-and-eye latch at a child-safe height.

Warranty and Support

• Limited manufacturer-backed warranty, confirmed during quote review.
• Quote review includes opening measurements, configuration choice, and a hardware kit recommendation.

Frequently Asked Questions

Which configuration should I pick for a dog household?
Pet Grille protects the lower mesh from scratching and leaning, best when the pet stays inside. Pet Flap adds a tinted vinyl pet entry rated to 90 lb with a lock-out slide, best when the pet comes and goes.

Does it come with hinges and a handle?
No, base doors ship without hardware. A composite kit with three adjustable spring-loaded self-closing hinges, two pulls, and a hook-and-eye latch is quoted on request in white or black.

Can I trim it to fit my opening?
Yes. The frame allows up to 3/8 in off the top and each side and up to 1 in off the bottom. Trim evenly, then seal the cut edges before hanging.

How do I finish it?
The wood arrives unfinished. Apply exterior paint or stain to all six sides, and on the Pet Grille and Pet Flap models the screen frame detaches so you can finish the door cleanly and reinstall the mesh.

Documents

• Product Submittal Summary (PDF)
• Dimensional & Fit Reference (PDF)
• Installation & Warranty Reference (PDF)

Project pricing, lead time, freight routing, and final configuration are confirmed during quote review before order release.

Support and request quote workflows stay available throughout specification and order planning.
