Door Axis 36 in x 80 in White Full View Aluminum Storm Door with Retractable Insect Screen
Reviewed pricing, lead time, freight, and final configuration are confirmed during quote review before order release.
The Door Axis Full View Aluminum Storm Door puts a full-height tempered glass panel in front of the entry door and hides a retractable insect screen inside the top rail, so the view stays clear until the moment you want airflow. It serves homeowners who want an unobstructed look at their front door year round, without seasonal glass and screen panels to swap and store.
The frame is heavy duty aluminum, 1-1/4 in thick with reinforced internal corner brackets, hung on a tamper-resistant hinge rail that mounts to either side of the opening. The full view glass runs from the top rail to the kick rail, and the built-in insect screen pulls down across the opening with one hand and retracts out of sight when not in use, no tools and no storage shelf required. Two closers control the swing, including a foot-activated hold-open at the base that keeps the door open hands free while you carry groceries through. The handle set with a built-in keyed deadbolt comes installed in a nickel finish, perimeter weatherstripping and a color-matched sweep seal the frame, and the unit is prepped for installation in about two hours with basic tools and no sawing. Four factory finishes cover white, warm neutrals, and a deep earth brown.
Highlights
- Full view tempered glass from top rail to kick rail
- Built-in retractable insect screen deploys and hides with one hand
- Heavy duty 1-1/4 in aluminum frame with reinforced corner brackets
- Universal Reversible hinge rail mounts left or right
- Foot-activated hold-open closer for hands-free entry
- Handle set with built-in keyed deadbolt, included
- Perimeter weatherstripping with color-matched sweep
- Prepped for about a two hour install with no sawing
Specification Table
| Configuration | Single full view storm door with retractable insect screen |
| Nominal sizes | 30, 32, or 36 in wide x 80 in tall |
| Fits opening | 35-3/4 to 36-3/8 in x 80 to 81 in at the 36 in size; smaller sizes hold the same tolerance from nominal |
| Frame | 1-1/4 in heavy duty aluminum with reinforced internal corner brackets |
| View | Full view, glass from top rail to bottom rail |
| Glazing | Full-height tempered glass panel |
| Screen | Built-in retractable insect screen, one hand operation |
| Handing | Universal Reversible, set at installation |
| Closers | Standard closer plus foot-activated hold-open closer |
| Hardware | Nickel handle set with built-in keyed deadbolt, included |
| Weatherstripping | Perimeter weatherstripping with color-matched door sweep |
| Finishes | White, Almond, Sandtone, Terratone |
| Weight | About 70 lb at 36 in x 80 in |
| Warranty | Limited manufacturer-backed warranty, confirmed during quote review |
Included Components
- Full view aluminum storm door with tempered glass panel
- Built-in retractable insect screen, factory fitted
- Nickel finish handle set with built-in keyed deadbolt
- Standard closer and foot-activated hold-open closer
- Tamper-resistant hinge rail and mounting hardware
- Color-matched door sweep, weatherstripping, and installation instructions
Installation Notes
- Measure the existing entry opening width and height at three points each; order the size whose fits-opening range brackets the smallest measurements.
- Check the mounting surface: the entry door frame face must be flat, sound, and at least 1 in deep for the hinge and latch rails along their full height.
- Choose the hinge side to match the entry door so both doors swing the same way; the hinge rail is reversible and mounts to either side.
- Adjust both closers after hanging: set the swing speed so the door closes fully without slamming, and test the foot-activated hold-open through several cycles.
- Run the retractable screen through its full travel after installation and confirm it seats in the side tracks without binding before finishing the sweep adjustment.
Warranty and Support
- Limited manufacturer-backed warranty, confirmed during quote review.
- Quote review includes an opening measurement check against the fits-opening ranges and finish confirmation before release.
Frequently Asked Questions
How is this different from an interchangeable storm door?
An interchangeable door ships separate glass and screen inserts that you swap seasonally and store. This platform builds the screen into the top rail: pull it down when you want airflow, retract it when you want the clear full view, nothing to store.
How do I measure my opening?
Measure the opening width between the inside faces of the entry door frame at the top, middle, and bottom, and the height on both sides and at the center. Order the size whose fits-opening range brackets your smallest width and height.
Can it hinge on either side?
Yes. The hinge rail is universal reversible and mounts to whichever side matches your entry door swing during installation.
Is the handle keyed?
Yes, the included handle set carries a built-in keyed deadbolt in a nickel finish. Other handle finishes are quoted on request.
Documents
- Type Aluminum Storm Door
- SKU DA-DR-STM-FV-RET-3680-WH
Download the available product documents below. If a document is not linked yet, use the SKU during quote review.
Project pricing, lead time, freight routing, and final configuration are confirmed during quote review before order release.
Support and request quote workflows stay available throughout specification and order planning.
