Door Axis 60 in x 80 in Full Lite Steel Prehung French Patio Door with Exterior Casing, Right-Hand Inswing
Reviewed pricing, lead time, freight, and final configuration are confirmed during quote review before order release.
The Door Axis 60 in x 80 in Full Lite Steel Prehung French Patio Door pairs two full glass steel slabs on one frame, with the right panel swinging into the room and the left panel fixed. It serves homeowners and remodelers who want the light of a full glass patio wall with the security and thermal performance of a solid core steel door, delivered as a ready-to-set prehung unit with exterior casing.
Each slab is built from steel skins over a solid polyurethane foam core, which insulates far better than a hollow door and stiffens the panel against twisting. The full lite opening carries insulated tempered clear glass in a dual pane package, the bottom rail is a rot-resistant composite, and the unit hangs in a wood jamb with an aluminum sill, factory applied compression weatherstripping, and exterior casing already attached. The active slab arrives double bored at a 2-3/8 in backset so a standard lockset and deadbolt drop straight in, and the primed white surface is ready for finish paint inside and out. As a hinged French unit it needs clear floor space for the inswing panel but offers a full-height weather seal on all four edges, which sliding doors cannot match.
Highlights
- Complete prehung unit: two slabs, wood jamb, aluminum sill, exterior casing
- Solid polyurethane foam core with steel skins for insulation and security
- Full lite insulated tempered clear glass in both slabs
- Right-Hand Inswing active panel; fixed companion panel
- Compression weatherstripping seals all four slab edges
- Rot-resistant composite bottom rail over an aluminum sill
- Double bored active slab accepts standard lockset and deadbolt at 2-3/8 in backset
- Primed white steel, ready for finish paint
Specification Table
| Configuration | Double door prehung French unit, one active and one fixed panel |
| Unit size | 60 in wide x 80 in tall nominal (two 30 in slabs) |
| Rough opening | 62.5 in x 82.5 in (typical; confirmed during quote review) |
| Slab thickness | 1-3/4 in |
| Core and material | Solid polyurethane foam core, steel skins, engineered wood frame |
| Glazing | Full lite insulated tempered clear glass, dual pane |
| Handing | Right-Hand Inswing, viewed from outside |
| Jamb | Wood jamb, 4-9/16 in typical depth, exterior casing applied |
| Hardware prep | Double bore on active slab, 2-3/8 in backset; hardware sold separately |
| Weatherstripping | High performance compression weatherstripping, factory applied |
| Sill | Aluminum sill with composite bottom rail |
| Finish | Primed white, paint-ready |
| Insect screen | Screen kits for inswing units quoted separately |
| Weight | About 240 lb |
| Warranty | Limited lifetime manufacturer-backed warranty, confirmed during quote review |
Included Components
- Two full lite steel slabs, factory hung on standard hinges
- Wood jamb with exterior casing applied
- Aluminum sill with composite bottom rail
- Factory applied compression weatherstripping
- Double bore hardware prep on the active slab (lockset and deadbolt sold separately)
- Installation instructions
Installation Notes
- Verify the rough opening at about 62.5 in x 82.5 in, measured at three points each way; final dimensions are confirmed during quote review.
- Install a sill pan and integrate flashing with the water resistive barrier before setting the unit; the aluminum sill must bear continuously on a level subfloor.
- Set the unit plumb, level, and square, shimming behind each hinge and at the strike and head, then fasten through the jamb into the framing.
- Confirm interior floor clearance for the inswing panel, including rugs and thresholds, before final positioning.
- Paint all primed surfaces, including the top and bottom slab edges, promptly after installation to seal the steel skins and hold the warranty.
Warranty and Support
- Limited lifetime manufacturer-backed warranty, confirmed during quote review.
- Quote review includes rough opening verification and handing confirmation from your exterior-view photos or sketch.
Frequently Asked Questions
What rough opening do I need?
Plan about 62.5 in wide by 82.5 in tall for the 60 in x 80 in unit, and confirm on site at three measuring points each way. Final opening dimensions are verified during quote review.
How do I confirm Right-Hand Inswing is correct for my opening?
Stand outside facing the closed door. If the operating panel should have its hinges on the right and swing into the room, this unit matches. Other handings and sizes are quoted on request.
Why choose a hinged French patio door over a slider?
A hinged unit seals with compression weatherstripping on all four edges, gives a full clear opening through the active panel, and reads as traditional architecture. Choose a slider when interior floor space for the door swing is not available.
Is a screen or hardware included?
No. The active slab is double bored for a standard lockset and deadbolt at a 2-3/8 in backset, and inswing screen kits are quoted separately.
Documents
- Type Steel French Patio Door
- SKU DA-DR-PAT-STL-FL-PH-6080-RHI
Download the available product documents below. If a document is not linked yet, use the SKU during quote review.
