Door Axis Medium Duty Commercial Door Closer, Size 3, Matte Black
Reviewed pricing, lead time, freight, and final configuration are confirmed during quote review before order release.
The Door Axis Medium Duty Closer covers offices, tenant suites, and retail doors in a matte black housing that disappears against dark storefront frames. Size 3 power with adjustable closing and latching speeds.
The all-metal body closes left- or right-hinged doors up to 125 lb, at widths to 38 in interior and 30 in exterior, opening a full 180 degrees. Closing and latching speeds tune independently to kill slam, and the published UL 3-hour fire listing plus ADA compliance carry it through commercial review. Mounts standard, top jamb, or parallel.
Highlights
- Size 3 power for doors to 125 lb
- Matte black all-metal housing
- Adjustable closing and latching speeds
- 180 degree opening range
- ADA compliant, UL 3-hour published listing
- Three mounting patterns
Specification Table
| Function | Medium duty surface closer |
| Power | Size 3 |
| Door capacity | 125 lb; 38 in interior, 30 in exterior |
| Opening | 180 degree |
| Mounts | Standard, top jamb, parallel |
| Listings | ADA, UL 3-hour (published) |
| Body | Cast metal, 12-3/4 in |
| Warranty | 10 year limited |
Included Components
- Closer body
- Arm assembly
- Mounting fasteners
Installation Notes
- Verify door weight and width against the size 3 capacity before specifying.
- Tune latch speed so the door overcomes the latch without banging.
- Parallel mount keeps the arm tight to the frame on push-side installs.
Warranty and Support
- 10 year limited coverage, confirmed during quote review.
Frequently Asked Questions
Black shows scratches; how durable is the finish?
The matte black coating is a factory finish over metal, warrantied with the closer; touch-up guidance ships in the quote package.
Documents
- Type Door Closer
- SKU DA-DR-HW-CLS-MD
Download the available product documents below. If a document is not linked yet, use the SKU during quote review.
Project pricing, lead time, freight routing, and final configuration are confirmed during quote review before order release.
Support and request quote workflows stay available throughout specification and order planning.
