Door Axis Polished Brass Single Cylinder Deadbolt, Classic Round Trim
Reviewed pricing, lead time, freight, and final configuration are confirmed during quote review before order release.
The Door Axis Polished Brass Deadbolt is a classic round-trim single cylinder deadbolt for keyed entry openings. It serves replacement work and new installs where traditional brass hardware is specified.
A keyed exterior cylinder drives a full 1 in bolt throw, operated from inside by thumb turn. The latch carries a round corner faceplate, adjusts between 2-3/8 in and 2-3/4 in backsets to fit standard preparations, and ships with a matching round strike. The lock is ANSI Grade 3 (Good) certified for residential security and installs with a screwdriver on doors from 1-3/8 in to 1-3/4 in thick.
Highlights
- ANSI Grade 3 (Good) certified residential deadbolt
- Full 1 in bolt throw
- Adjustable 2-3/8 or 2-3/4 in backset
- Round corner faceplate with matching round strike
- Universal handing, screwdriver installation
- 2 keys included
- Lifetime mechanical and finish coverage
Specification Table
| Function | Single cylinder deadbolt |
| Security rating | ANSI Grade 3 (Good) |
| Trim | Round, classic |
| Bolt throw | 1 in |
| Backset | Adjustable 2-3/8 or 2-3/4 in |
| Face bore | 2-1/8 in |
| Door thickness | 1-3/8 to 1-3/4 in |
| Latch | Round corner faceplate |
| Finish | Polished Brass |
| Keys | 2 included |
Included Components
- One polished brass single cylinder deadbolt
- Interior thumb turn and exterior keyed cylinder
- Round deadbolt strike and mounting hardware
- Installation instructions
- 2 keys
Installation Notes
- Confirm the door has a standard 2-1/8 in bore; this unit is a drop-in replacement for existing deadbolt preps.
- Set the adjustable latch to the door backset before mounting the cylinder.
- Mortise the strike so the full 1 in throw seats; a short throw defeats the security rating.
- Snug the through-bolts evenly to keep the cylinder aligned with the thumb turn.
Warranty and Support
- Limited lifetime mechanical and finish coverage, confirmed during quote review.
Frequently Asked Questions
Will this fit my existing deadbolt cutout?
Yes, if the door has the standard 2-1/8 in bore and a 2-3/8 in or 2-3/4 in backset. The latch adjusts between both backsets.
Is the trim solid brass?
The finish is polished brass over a metal chassis. Finish composition details are confirmed during quote review.
Documents
- Type Deadbolt
- SKU DA-DR-HW-DBL-STD
Download the available product documents below. If a document is not linked yet, use the SKU during quote review.
