Door Axis Satin Nickel Single Cylinder Entry Handleset, Right-Hand Interior Lever
Reviewed pricing, lead time, freight, and final configuration are confirmed during quote review before order release.
The Door Axis Entry Handleset pairs an exterior grip and single cylinder deadbolt with a right-hand interior lever in satin nickel. It serves front doors hinged on the right when viewed from outside, where a modern two-piece handleset is specified.
The set is solid brass and certified ANSI Grade 2 (Better). Outside, the thumbpiece grip retracts the latch below a keyed, rekeyable deadbolt cylinder; inside, the lever releases the latch and a thumb turn throws the bolt. The through-bolt adjusts 1-1/2 in vertically to pick up existing holes on retrofit doors, and self-aligning screw holes speed a screwdriver installation. Fits doors 1-5/8 in to 1-3/4 in thick. This handing is right-hand only: standing outside, hinges on the right, interior lever pointing left.
Highlights
- Solid brass construction, satin nickel finish
- ANSI Grade 2 (Better) certified
- Single cylinder deadbolt with rekeyable cylinder
- Right-hand interior lever, stated handing
- Through-bolt adjusts 1-1/2 in for retrofit holes
- Fits 1-5/8 to 1-3/4 in doors
- Lifetime limited mechanical and finish coverage
Specification Table
| Function | Single cylinder entry handleset |
| Security rating | ANSI Grade 2 (Better) |
| Handing | Right-hand, interior lever points left |
| Construction | Solid brass, 2-piece front and back |
| Deadbolt bore | 2-1/8 in |
| Lever bore | 2.2 in |
| Door thickness | 1-5/8 to 1-3/4 in |
| Through-bolt | Adjustable, 1-1/2 in travel |
| Keying | Rekeyable cylinder, 2 keys |
| Finish | Satin Nickel |
Included Components
- Exterior grip with thumbpiece and keyed deadbolt cylinder
- Right-hand interior lever and thumb turn
- Latches, strikes, and self-guiding screws
- Drilling template and installation instructions
Installation Notes
- Confirm handing before ordering: stand outside the door; hinges on the right means right-hand.
- Verify the door is at least 1-5/8 in thick; thinner slabs need a different set, quoted on request.
- Use the adjustable through-bolt to pick up existing holes instead of redrilling the slab.
- Set both latches to the door backsets before mounting trim.
Warranty and Support
- Lifetime limited mechanical and finish coverage, confirmed during quote review.
Frequently Asked Questions
My door is hinged on the left. Will this work?
No, this set is right-hand only. A left-hand configuration is quoted on request from the same product line.
Can the lock be keyed to match my other doors?
The cylinder is rekeyable; keying requests are consolidated during quote review.
Does it fit a standard 1-3/8 in door?
No. This set requires 1-5/8 in to 1-3/4 in thickness; most entry slabs at 1-3/4 in qualify, but verify before ordering.
Documents
- Type Handleset
- SKU DA-DR-HW-HSET-GRIP1
Download the available product documents below. If a document is not linked yet, use the SKU during quote review.
