Fast Balcony Perforated Mesh Balcony Railing Panel System
Reviewed pricing, lead time, freight, and final configuration are confirmed during quote review before order release.
The Fast Balcony Perforated Mesh Balcony Railing Panel System frames perforated aluminum panels between welded posts, giving balconies, patios, and walkway edges privacy screening and guard function in one assembly. Architects specify it where sight-line control matters: pool decks, ground-floor patios, and balcony stacks facing each other across a courtyard.
Sections are welded aluminum post and rail frames carrying perforated aluminum panels, shipped in 4, 5, 6, and 8 ft lengths that assemble into continuous runs, with intermediate stiffeners on longer sections per the released engineering. The perforation pattern and open area are documented per project, which sets the balance between screening, daylight, and wind pressure. Standard guard height is 42 in with 36 in available where the project code allows. Sections bolt to the balcony frame, deck structure, or parapet without field welding, and the entire assembly powder coats as one color field in Matte Black, White, Bronze, or Slate Gray.
Highlights
- Framed perforated aluminum panels combine guard function and privacy screening
- Perforation pattern and open area documented per project engineering
- Welded aluminum sections in 4, 5, 6, and 8 ft lengths
- 42 in guard height standard; 36 in available where project code allows
- Panels, rails, and posts powder coat as one continuous color field
- Bolt-on surface mount to frame, deck, or parapet, no field welding
- Section weights 28 to 48 lb including one post per section for take-off math
Specification Table
| Section lengths | 4 ft, 5 ft, 6 ft, 8 ft; runs cut to project layout during quote review |
| Guard height | 42 in standard; 36 in available where project code allows |
| Construction | Welded aluminum posts and rails with framed perforated panels |
| Railing infill | Perforated aluminum mesh panels; pattern and open area per released engineering |
| Post program | Welded aluminum posts with base hardware; spacing per released engineering |
| Mount system | Surface mount to balcony frame, deck structure, or parapet |
| Installation | Bolt-on section installation, no field welding |
| Structural basis | Engineered to project live-load requirements; structural verification completed during quote review |
| Finish | Powder coat: Matte Black standard; White, Bronze, Slate Gray; custom colors quoted on request |
| Section weight | About 28 lb (4 ft), 33 lb (5 ft), 38 lb (6 ft), 48 lb (8 ft), including one post per section (engineering estimate) |
| Lead time | Confirmed during quote review; typical production runs are scheduled after drawing approval |
| Freight | Ships by commercial freight; freight confirmed during quote review |
| Warranty | Warranty coverage for the final quoted configuration is documented and confirmed during quote review |
Included Components
- Welded aluminum railing sections with framed perforated panels in the selected length
- One welded aluminum post with base hardware per section; corner and starter posts scoped at quote review
- Section splice and mounting hardware per the released details
- Powder coat finish in the selected color across frames and panels
Installation Notes
- Guard attachment is structural: substrate, blocking, and anchorage must be verified by the project engineer of record, with structural verification completed during quote review.
- Lay out post locations from the released engineering before drilling.
- Bolt posts to the structure per the released details, set sections, and splice per the installation documents; keep panel faces protected from dragging during handling.
- Check panel alignment across section joints before final torque so the perforation pattern reads continuous.
- Wash powder coated surfaces with mild detergent and water; avoid abrasive pads and solvent cleaners.
Warranty and Support
- Warranty coverage for the final quoted configuration is documented and confirmed during quote review.
- AAMA 2604-class powder coat performance is available and confirmed during quote review.
Frequently Asked Questions
How much privacy do the panels provide?
The perforation pattern and open area are set per project, so the screening level is a design choice. Smaller open areas read nearly solid at a distance while still passing light and air; the pattern is documented during quote review.
How do the panels handle wind?
Perforated panels pass a share of wind pressure rather than blocking it like solid infill, and the released engineering accounts for the selected open area on the project exposure. That review is completed during quote review.
Can panels be used on ground-level patios?
Yes. The same sections surface-mount at grade for patio guards and privacy screens, with anchorage details per substrate in the released installation documents.
How do I estimate sections for my run?
Divide the run by the section lengths, favoring 8 ft sections on straight runs. Send the run drawing with the quote request; the section schedule and corner posts are confirmed during quote review.
Documents
- Type Balcony Railing System
- SKU FB-BAL-RAIL-MESH-L4-BK
Download the available product documents below. If a document is not linked yet, use the SKU during quote review.
Project pricing, lead time, freight routing, and final configuration are confirmed during quote review before order release.
Support and request quote workflows stay available throughout specification and order planning.
