Light Archon Clarion 5.25 in. 1-Light Wall Fixture with Outlet and Pull Chain, Chrome

The Light Archon Clarion is the classic utility wall fixture done properly: one E26 lamp behind a white and crystal-textured glass hexagon, a pull chain for switching at the fixture, and a convenience outlet on the chrome base for a razor, toothbrush charger, or nightlight. It is the fixture that solves older baths, workrooms, and utility walls where the box is live but there is no wall switch. Quote-first program: no public prices, add it to a quote list for project terms.

The pull chain means the Clarion switches itself: wire it to a constantly hot 120V circuit and occupants control the light at the fixture, while the outlet on the base stays live for small appliances. The textured glass spreads the lamp softly for over-mirror and over-sink duty, and the chrome base wipes clean in damp rooms; the platform is damp rated for bathroom moisture zones. It takes one medium-base lamp up to 60 watts or the LED equivalent through the open-bottom shade. The 4.75 in. square backplate covers a standard wall J-box in either orientation. This is a hard-working replacement for aging builder fixtures, one-for-one, without rewiring.

Highlights

• Integral pull chain switches the light at the fixture
• Convenience outlet on the base for small appliances
• White and crystal-textured glass hexagon shade
• Chrome finish wipes clean in damp rooms
• One E26 socket, 60 watts max, LED compatible
• Damp rated for bath and utility walls
• 4.75 in. square backplate covers a standard wall J-box
• Drop-in replacement for aging builder fixtures

Specification Table

Included Components

• Wall fixture with hexagon glass shade
• Backplate and mounting hardware
• Pull chain installed
• Lamp not included, specified at quote

Installation Notes

• Hardwired to a 120V circuit; de-power at the panel before work.
• Mounts to a standard wall J-box behind the 4.75 in. square backplate.
• Wire to a constantly hot circuit so the outlet stays live and the pull chain switches the lamp.
• Typical placement is over a mirror or workbench, 66 to 72 in. to center.
• Damp rated: bath and utility walls supported, direct water contact is not.

Warranty and Support

• Limited platform warranty confirmed on the quote sheet
• Quote-first program: no public prices; submit the list for project terms

Frequently Asked Questions

What does the Clarion mount to?
A standard wall J-box behind the 4.75 in. square backplate. It replaces older builder fixtures one-for-one on the same box.

Does the outlet need its own wiring?
No. The fixture wires once to a 120V supply; the base outlet taps that supply and the pull chain switches only the lamp. Wire it to a constantly hot circuit so the outlet works with the light off.

Is it allowed in a bathroom?
Yes, it is damp rated for bathroom walls. Follow local code on receptacle placement relative to sinks and tubs, and keep the fixture out of direct water contact.

What lamp should I use?
One E26 lamp up to 60 watts or the LED equivalent. A frosted A19 in 2700K to 3000K reads soft through the textured glass.

Documents

• Product Submittal Summary (PDF)
• Dimensional & Fit Reference (PDF)
• Installation & Warranty Reference (PDF)

Project pricing, lead time, freight routing, and final configuration are confirmed during quote review before order release.

Support and request quote workflows stay available throughout specification and order planning.
