Light Archon Nimbus 46 in. Integrated LED Flush Mount DC Ceiling Fan with Remote and App Control, Black

The Light Archon Nimbus packs a 6-speed reversible DC motor into a 46 in. low-profile flush mount, moving up to 4790 CFM while holding noise under 35 dB per source documentation. The integrated LED kit delivers 1860 lumens with three selectable color temperatures, and control runs from the included handheld remote or a companion app with no hub required. Pricing is quote-based: add it to a quote list and the desk confirms configuration and delivery.

DC motors earn their keep two ways: more speeds with finer steps, and a fraction of the energy draw of an AC equivalent. The Nimbus gives six speeds forward and reverse, so summer cooling and winter recirculation both land on the right setting. The light kit switches between 3000K warm, 4500K neutral, and 6000K cool white from the remote, with brightness adjustment to match. Five plywood blades ride under the housing in a matte black package 9.5 in. tall, and the damp rating covers covered patios as well as bedrooms, offices, and living rooms. It mounts only to a listed fan-rated outlet box; there is no downrod, keeping it a true low-profile install. ETL certified.

Highlights

• 46 in. span moves up to 4790 CFM on high
• 6-speed reversible DC motor, under 35 dB per source documentation
• Integrated LED: 1860 lumens, 3000K, 4500K, or 6000K selectable
• Handheld remote plus companion app control, no hub required
• Low 9.5 in. profile for 8 ft. ceilings
• Damp rated: covered patios and interiors
• 5 plywood blades in matte black
• ETL certified platform

Specification Table

Included Components

• Fan motor assembly with black housing
• 5 plywood blades
• Integrated LED light kit with shade
• Handheld remote control
• Flush mounting bracket and hardware

Installation Notes

• Mount only to an outlet box listed for ceiling fan support (fan-rated); a standard light-fixture box is not acceptable.
• Maintain at least 7 ft. from floor to blades and 18 in. from blade tips to the nearest wall.
• Flush mount design; no downrod is included per source documentation.
• Pair the companion app after power-up per the included guide; the remote works out of the box.
• Damp rated: covered patios supported, direct rain exposure is not.

Warranty and Support

• 1-year limited warranty program confirmed at quote review
• Specifier support and submittal documents available on request
• Replacement remote and blade paths confirmed at quote review

Frequently Asked Questions

Do I need a special outlet box?
Yes. Every ceiling fan must hang from an outlet box listed for fan support (fan-rated). If the existing box is a standard light-fixture box, plan a fan-rated pancake or deep box at rough-in or retrofit.

Can I use it on a covered porch?
Yes. The platform is damp rated for covered outdoor spaces such as porches and patios. It is not rated for direct rain exposure.

What does the app add over the remote?
The companion app duplicates speed, light, and reverse control from a phone with no hub required, and serves as backup when the remote is misplaced. The included remote covers everything day to day.

How quiet is the DC motor?
The source documentation lists operation under 35 dB, which reads as a whisper in a quiet bedroom. Six speeds let you trade airflow against sound precisely.

Documents

• Product Submittal Summary (PDF)
• Dimensional & Fit Reference (PDF)
• Installation & Warranty Reference (PDF)

Project pricing, lead time, freight routing, and final configuration are confirmed during quote review before order release.

Support and request quote workflows stay available throughout specification and order planning.
