Light Archon Quanta 24 in. Selectable CCT Integrated LED Linear Vanity Light, Brushed Nickel

The Light Archon Quanta is a 24 in. linear vanity light that lets the installer pick the color temperature at the fixture: 2700K, 3000K, 3500K, 4000K, or 5000K from one integrated LED array, so a single SKU covers every bath standard on the project schedule. Output is 1700 lumens at a premium 90 CRI, diffused through a slim rectangular shade with metal endcaps over a square brushed nickel backplate. Quote-first program: no public prices, add it to a quote list for project terms.

Selectable CCT is the specifier's insurance policy: set 2700K for a warm residential bath, 3500K for a neutral multi-family standard, or 5000K where a daylight reading is required, all on the same fixture and without restocking. The 90 CRI array reads skin tones honestly and diffuses spot-free through the shade per source documentation. The platform is cETLus listed for damp locations, complies with California Title 24 JA8, and carries an ADA-compliant slim projection, which makes it a clean fit for accessible bath layouts. It installs horizontally over a standard wall J-box behind the 5 in. square backplate, dims with compatible wall dimmers, and hardwires to a 120V circuit. Mounting hardware ships in the box.

Highlights

• 5 selectable color temperatures: 2700K to 5000K
• 1700 lumens at 90 CRI from an integrated LED array
• 24 W array replaces lamp-and-socket maintenance
• Slim rectilinear profile with metal endcaps, ADA per source documentation
• cETLus damp location listed; Title 24 JA8 compliant
• Dimmable with compatible wall dimmers
• 5 in. square backplate lands on a standard wall J-box
• Suits vanities and mirrors 26 in. and up

Specification Table

Included Components

• Selectable CCT LED vanity bar
• Square backplate and mounting hardware
• Installation instructions

Installation Notes

• Hardwired to a 120V circuit; de-power at the panel before work.
• Mounts horizontally to a standard wall J-box behind the 5 in. square backplate.
• Set the CCT selector to the scheduled color temperature before closing up.
• Pair with a compatible LED wall dimmer for level control.
• Damp rated: suitable for bath moisture zones, not for direct water contact.

Warranty and Support

• 5-year limited warranty program confirmed on the quote sheet
• Quote-first program: no public prices; submit the list for project terms

Frequently Asked Questions

What does the Quanta mount to?
A standard wall J-box, horizontal orientation, behind the 5 in. square brushed nickel backplate. Mounting hardware is included.

How does the CCT selection work?
A selector on the fixture chooses 2700K, 3000K, 3500K, 4000K, or 5000K from the same LED array. Set it at install; occupants simply see the chosen white.

Is it suitable for accessible (ADA) bath layouts?
Yes per source documentation: the slim projection keeps the fixture within accessible protrusion limits, and the platform is also California Title 24 JA8 compliant.

Can it be dimmed?
Yes, with compatible LED wall dimmers, down to evening levels at any selected color temperature.

Documents

• Product Submittal Summary (PDF)
• Dimensional & Fit Reference (PDF)
• Installation & Warranty Reference (PDF)

Project pricing, lead time, freight routing, and final configuration are confirmed during quote review before order release.

Support and request quote workflows stay available throughout specification and order planning.
