Light Archon Zephyr 48 in. Integrated LED Flush Mount Ceiling Fan with Wall Control, Flat White

The Light Archon Zephyr is a 48 in. flush mount ceiling fan in flat white that disappears into the ceiling plane, then proves itself with 3891 CFM from a quiet-engineered AC motor. Three clean blades and an integrated 16 W LED light kit keep the profile minimal, and control comes from an included wall-mounted controller with four speeds and a full-range light dimmer, so nothing lives on a nightstand to get lost. Pricing is quote-based: add it to a quote list for project terms.

At 10 in. from ceiling to the bottom of the fixture, the Zephyr is built for 8 ft. ceilings where headroom is the constraint. The 12 degree blade pitch and 189 RPM top speed move real air for rooms to about 12 ft. x 12 ft., and the reversible motor recirculates warm ceiling air in winter. The 824.6 lumen light kit reads warm at 3000K and dims smoothly across its full range from the wall control. The platform is ETL certified for dry interior locations and mounts only to a listed fan-rated outlet box; it is a dedicated flush mount design, with no downrod included per source documentation. A limited lifetime motor warranty program backs the drivetrain.

Highlights

• 48 in. span moves up to 3891 CFM on high
• Flush mount preserves headroom on 8 ft. ceilings
• Included wall control: 4 speeds plus full-range dimmer
• Integrated LED light kit: 824.6 lumens at 3000K
• 3 blades at a 12 degree pitch for efficient airflow
• Reversible motor for summer and winter operation
• Quiet motor engineering per source documentation
• ETL certified; limited lifetime motor warranty program

Specification Table

Included Components

• Fan motor assembly with flat white housing
• 3 flat white blades
• Integrated LED light kit
• Wall-mounted control with full-range dimmer
• Flush mounting bracket and hardware

Installation Notes

• Mount only to an outlet box listed for ceiling fan support (fan-rated); a standard light-fixture box is not acceptable.
• Maintain at least 7 ft. from floor to blades and 18 in. from blade tips to the nearest wall.
• Flush mount design for flat ceilings; no downrod is included per source documentation.
• Install the wall control on the switched leg per the included wiring diagram.
• Installation should be completed by a qualified electrician on a 120V circuit.

Warranty and Support

• Limited lifetime motor warranty program; 1-year limited fan warranty confirmed at quote review
• Specifier support and submittal documents available on request
• Replacement blade and shade paths confirmed at quote review

Frequently Asked Questions

Do I need a special outlet box?
Yes. Every ceiling fan must hang from an outlet box listed for fan support (fan-rated). If the existing box is a standard light-fixture box, plan a fan-rated pancake or deep box at rough-in or retrofit.

Where does the control mount?
The included controller replaces or supplements the wall switch: four fan speeds and a full-range light dimmer live at the wall, so there is no handheld remote to lose.

Will it work on a sloped or tall ceiling?
No. The Zephyr is a dedicated flush mount platform for flat ceilings and does not take a downrod per source documentation. For sloped or tall ceilings, specify a downrod-mount platform instead.

Which rooms does a 48 in. span suit?
Rooms to about 12 ft. x 12 ft.: bedrooms, offices, kitchens, and dens. The flush profile makes it the default pick for 8 ft. ceilings.

Documents

• Product Submittal Summary (PDF)
• Dimensional & Fit Reference (PDF)
• Installation & Warranty Reference (PDF)

Project pricing, lead time, freight routing, and final configuration are confirmed during quote review before order release.

Support and request quote workflows stay available throughout specification and order planning.
