Namimera 20-1/2 in. Undermount Rectangular Vitreous China Bathroom Sink, White
Reviewed pricing, lead time, freight, and final configuration are confirmed during quote review before order release.
This designer-ready product summary covers a 20-1/2 x 15-3/4 in. undermount rectangular vitreous china bathroom sink with a 17-5/8 x 13-1/8 in. bowl, overflow drain, 1-3/4 in. drain hole, and counter- or wall-mount faucet compatibility, helping kitchen and bath programs move from review to release with fewer scope gaps.
Highlights
- Rectangular undermount basin creates a seamless counter line
- Durable glazed vitreous china construction
- 17-5/8 x 13-1/8 in. bowl with 5-5/16 in. depth and overflow drain
- No deck holes; pairs with counter-mount or wall-mount faucets
- Basin clamps included for undermount attachment
- ADA and CSA B651 compliant when installed to the specific requirements of these regulations
Specification Table
| Overall dimensions | 20-1/2 x 15-3/4 x 7-5/16 in. |
| Bowl dimensions | 17-5/8 x 13-1/8 in. |
| Bowl depth | 5-5/16 in.; 3-5/8 in. water depth |
| Material | Vitreous china |
| Mounting | Undermount with included basin clamps |
| Faucet holes | None; wall-mount or counter-mount faucet required |
| Overflow | Yes, overflow drain |
| Drain hole | 1-3/4 in. |
| Standards | ASME A112.19.2/CSA B45.1 |
| Accessibility | ADA and CSA B651 compliant when installed per regulation requirements |
| Warranty | Limited lifetime warranty on vitreous china |
Included Equipment
- Vitreous china sink basin
- Basin clamps for undermount attachment
- Installation guide
Installation Notes
- The undermount cutout template is required for fabrication and is not packed with the sink; request the current template during quote review before the countertop is cut.
- Faucet drilling happens in the countertop or wall; coordinate faucet centers with the fabricator since the basin has no deck holes.
- Support the basin with the included clamps and fabricator-approved adhesive per the installation guide.
- Final drain and supply connections should be completed by a qualified, licensed plumber.
- Review the final configuration and accessory bundle during quote review before order release.
Warranty and Support
- Published warranty coverage: limited lifetime warranty on the vitreous china basin
- Current cutout templates and installation documents are supplied through quote review
- Final warranty registration and coverage documents are confirmed during quote review
Frequently Asked Questions
Does this sink come with faucet holes?
No. Undermount basins mount below the counter, so the faucet installs in the countertop or wall. Coordinate drilling with the fabricator.
Is a cutout template included?
No. The published documentation lists the cutout template as required but not packed with the sink; it is supplied through quote review before fabrication.
Is this sink ADA compliant?
The published specification summary lists ADA and CSA B651 compliance when the sink is installed to the specific requirements of those regulations, including rim height and clearances.
Does it have an overflow?
Yes. The basin includes an overflow drain and a 1-3/4 in. drain hole.
Documents
- Type Undermount Bathroom Sink
- SKU NM-PLB-SK-UM20-WH-WH
Download the available product documents below. If a document is not linked yet, use the SKU during quote review.
Project pricing, lead time, freight routing, and final configuration are confirmed during quote review before order release.
Support and request quote workflows stay available throughout specification and order planning.
