Namimera 60 in. Alcove Soaking Bathtub with Integral Apron, White
Reviewed pricing, lead time, freight, and final configuration are confirmed during quote review before order release.
This contractor-ready product summary covers a 60 in. acrylic alcove soaking tub in 30.25 in. or 32 in. widths with left or right drain, 9 in. soaking depth, 42 gal capacity, integral tiling flange and apron, and a 22 degree lumbar backrest, helping plumbing crews and remodel programs move from review to release with fewer scope gaps.
Highlights
- Fits standard 60 in. three-wall alcoves in 30.25 in. or 32 in. widths
- Left or right drain orientation to match existing rough plumbing
- 9 in. soaking depth with 42 gal capacity on the 30.25 in. width; 9-1/8 in. and 40.6 gal on the 32 in. width
- Integral apron and tiling flange for a clean, finished, leak-resistant installation
- 22 degree backrest angle with integral lumbar support
- Textured bottom surface and low step-over height
- Lightweight acrylic, about 66 lb, sets without a crane crew
- Certified to CSA B45.5/IAPMO Z124; lifetime limited warranty
Specification Table
| Overall dimensions | 60 x 30.25 x 15.75 in. or 60 x 32 in., by size selection |
| Soaking depth | 9 in. (30.25 in. width); 9-1/8 in. (32 in. width) |
| Capacity | 42 gal (30.25 in. width); 40.6 gal (32 in. width) |
| Basin area, bottom | 45-3/16 x 20-5/8 in. (30.25); 45-1/16 x 24-3/8 in. (32) |
| Material | Acrylic with textured bottom |
| Installation | Three-wall alcove, integral flange, integral apron |
| Drain | Left or right; standard 1-1/2 in. bath drain, sold separately |
| Backrest | 22 degree lumbar angle |
| Minimum floor load | 36 lb per sq ft |
| Weight | 66 lb (30.25 in. width); 66.3 lb (32 in. width) |
| Certifications | CSA B45.5/IAPMO Z124; ASTM E162, E662 |
| Warranty | Lifetime limited warranty |
Included Equipment
- Acrylic alcove bath with integral apron and tiling flange
- Installation guide
Installation Notes
- Confirm alcove width, stud-wall plumb, and drain rough-in side against the selected size and drain orientation before ordering; measure the actual unit for rough-in details.
- Set the tub in a full mortar bed or high-quality construction adhesive per the guide; never support the bath by the rim.
- Size the water heater so hot supply covers at least 70 percent of the bath capacity.
- Drain and overflow assembly are by the installer; final connections should be completed by a qualified, licensed plumber.
- Review the final size, drain side, and accessory bundle during quote review before order release.
Warranty and Support
- Published warranty coverage: lifetime limited warranty on the acrylic bath
- Care guidance for acrylic surfaces is provided with the quote package
- Final warranty registration and coverage documents are confirmed during quote review
Frequently Asked Questions
Which drain side do I need?
Stand facing the alcove: if the existing waste rough-in sits on your left, order the left drain. Both orientations are stocked in the 60 x 30.25 in. and 60 x 32 in. sizes.
How deep does the water get?
The published specification summary lists 9 in. of soaking depth and 42 gal capacity for the 30.25 in. width, and 9-1/8 in. with 40.6 gal for the 32 in. width.
Does it need a mortar bed?
The installation guide calls for a mortar bed or approved construction adhesive under the basin to prevent flex and cracking, plus flange attachment to the studs.
Is a shower valve or drain included?
No. The bath ships as the shell with integral apron; drain, overflow, and valve trim are selected during quote review.
Documents
- Type Alcove Bathtub
- SKU NM-PLB-TB-AL60-WH-6030L
Download the available product documents below. If a document is not linked yet, use the SKU during quote review.
Project pricing, lead time, freight routing, and final configuration are confirmed during quote review before order release.
Support and request quote workflows stay available throughout specification and order planning.
