Namimera 60 in. L x 32 in. W Alcove Shower Base with Low Threshold, White
Reviewed pricing, lead time, freight, and final configuration are confirmed during quote review before order release.
This contractor-ready product summary covers a 60 in. x 32 in. direct-to-stud alcove shower base with a left, center, or right drain position selected at quote, 3.5 in. low threshold, reinforced no-mortar support, slip-resistant floor, and caulkless flange seams, helping plumbing crews and property teams move from review to release with fewer scope gaps.
Highlights
- 60 in. x 32 in. alcove footprint fits standard tub replacements
- Low 3.5 in. threshold for easy entry
- Available in left, center, or right drain configurations
- Reinforced base needs no mortar bed on level subfloors
- Direct-to-stud install with built-in nailing flanges
- Caulkless flange seals against the matching wall set
- Slip-resistant, easy-clean high-gloss acrylic surface
- Rated for 300 lb user weight
Specification Table
| Nominal size | 60 in. L x 32 in. W |
| Actual dimensions | 59.88 in. L x 32 in. W x 4.88 in. H |
| Threshold height | 3.5 in. |
| Drain position | Left, center, or right (selected at quote) |
| Material | High-gloss acrylic surface, reinforced base |
| Installation | Direct-to-stud alcove, nailing flanges |
| Mortar bed | Not required on level subfloors |
| Floor | Slip resistant |
| Load rating | 300 lb user weight |
| Color | High-gloss white |
| Warranty | 10-year limited residential |
Included Equipment
- Alcove shower base
- Installation instructions
Installation Notes
- Confirm drain rough-in matches the selected drain position (left, center, or right) before ordering; a standard 4-1/4 in. round shower drain is supplied separately.
- Check the subfloor for level; the reinforced base sets without a mortar bed on level framing.
- Fasten the nailing flanges direct to studs and verify the pan sits flat before wall panels go on.
- Pair with the matching 60 x 32 direct-to-stud wall set for the caulkless seam system.
- Review the final configuration and accessory bundle during quote review before order release.
Warranty and Support
- Published warranty coverage: 10-year limited warranty for residential use, 1 year for commercial applications
- Support for flange and seam questions is available through quote review
- Final warranty registration and coverage documents are confirmed during quote review
Frequently Asked Questions
Does it include the drain?
No. The base accepts a standard 4-1/4 in. round shower drain, supplied and installed separately.
Do I need a mortar bed?
No mortar bed is required on level subfloors; the base carries reinforced integral support.
Can it be used with tile walls?
Yes. The base installs under tile applications as well as the matching wall set. Seal the perimeter per the project spec when tiling.
What should be confirmed before ordering?
Drain location, alcove framing dimensions, and subfloor level are confirmed during quote review.
Documents
- Type Alcove Shower Base
- SKU NM-PLB-SB-6032-WH-L
Download the available product documents below. If a document is not linked yet, use the SKU during quote review.
