Namimera Single-Handle 1-Spray Shower Faucet with Pressure Balance Valve, 1.75 GPM, Chrome
Reviewed pricing, lead time, freight, and final configuration are confirmed during quote review before order release.
This contractor-ready product summary covers a wall-mount single-handle shower faucet with an included pressure-balance rough-in valve, a 2.75 in. single-spray head, a solid forged brass body, and 1.75 GPM WaterSense flow, helping plumbing crews and property teams move from review to release with fewer scope gaps.
Highlights
- Complete unit: trim, single-spray head, arm, flange, and rough-in valve
- Pressure-balancing cartridge holds mix when other fixtures draw water
- Field-adjustable hot limit stop caps handle rotation into the hot zone
- 2.75 in. round head with easy-clean rubber nozzles
- 7 in. escutcheon with etched hot and cold indicators covers most wall openings
- Solid forged brass valve body; all parts serviceable from the front
- 1.75 GPM maximum flow at 80 psi, WaterSense labeled, ADA compliant valve control
- Chrome finish suits maintenance stock standardization
Specification Table
| Valve type | Pressure balance cycle cartridge, adjustable hot limit |
| Valve included | Yes, rough-in valve in box; 1/2 in. male NPT with copper solder option |
| Flow rate | 1.75 GPM at 80 psi |
| Spray settings | 1, full body; easy-clean nozzles |
| Head size | 2.75 in. round |
| Escutcheon | 7 in. plate with H and C indicators |
| Overall height | 13-1/2 in. |
| Body material | Solid forged brass |
| Handle | Single lever, 120 degree rotation |
| Mounting | Wall mount, back-to-back capable |
| Certifications | WaterSense, ADA valve control, ASME A112.18.1/CSA B125.1 |
| Warranty | Lifetime limited, residential; 10 yr multifamily, 5 yr commercial |
Included Equipment
- Pressure-balancing rough-in valve, 1/2 in. male NPT with copper solder option
- Valve trim with lever handle and 7 in. escutcheon
- Single-spray shower head
- Shower arm and flange
- Installation instructions
Installation Notes
- Shut off supplies and confirm 1/2 in. male NPT or sweat connections before setting the valve body.
- Keep the wall opening smaller than the 7 in. escutcheon so the plate fully covers it.
- Set the hot limit stop at commissioning; the handle controls temperature only.
- Rough-in and final connection should be completed by a qualified, licensed plumber.
- Review the final finish selection and accessory bundle during quote review before order release.
Warranty and Support
- Published warranty coverage: lifetime limited parts and finish warranty for residential installations, 10 years multifamily and 5 years other commercial
- Replacement cartridges, handles, and escutcheons are supported through quote review
- Final warranty registration and coverage documents are confirmed during quote review.
Frequently Asked Questions
Is the rough-in valve included?
Yes. The complete unit ships with the pressure-balancing rough-in valve, trim, head, arm, and flange.
Can the maximum hot water temperature be limited?
Yes. The cartridge has a field-adjustable rotational limit stop that caps how far the handle turns into the hot zone.
Is the flow rate code-compliant?
The published specification summary lists 1.75 GPM at 80 psi with a WaterSense label and ASME A112.18.1/CSA B125.1 compliance. Local code requirements should be confirmed during quote review.
What should be confirmed before ordering?
Supply connection type at the valve, wall opening size versus the 7 in. escutcheon, and quantity for the program are confirmed during quote review.
Documents
- Type Shower Faucet Set
- SKU NM-PLB-SV-PB1S-CH-CH
Download the available product documents below. If a document is not linked yet, use the SKU during quote review.
